AGM Asp-Micro TM160 Thermal Monocular


Pre-Order yours now with $50 down! “Remaining balance of $349 will be due at time of shipment”


SKU: 3093251001AM10 Category:


AGM Asp-Micro TM160

The Asp-Micro handheld observational thermal monocular is equipped with a 160×120 and a 720×540 LCOS display. It supports functions of observation, highest temperature target tracking, distance measurement, Wi-Fi hotspot, and so on. The high-sensitivity built-in thermal detector provides you with clear view even in total darkness.

Asp-Micro TM160 Highlights:

Magnification 1x-4x
Detection Range ≈ 200 yards
Core/Pixel Pitch/Frame Rate 160×120, 17μm, 50Hz
Battery Built-in rechargeable Lithium battery / ≈ 7hrs runtime
Video Yes
Audio No
Picture in Picture No
Warranty 3 years

Asp-Micro TM160 FUNCTIONS:

Distance Measurement:
The device realizes distance measurement function after marking the top and bottom of target, and input the target height.
Hot Spot Mark:
The device detects and marks the hot spot of highest temperature.
Mode Switch:
Device supports pallet switch and distance measurement.
Built-in memory module supports video recording/snapshot capturing.
Digital Zoom:
Device supports 1×, 2×, and 4× digital zoom.
Wi-Fi Hotspot:
Device can capture snapshots, record videos, and set parameters via APP after being connected to your phone.

  • 160×120 or 384×288 resolution, high sensitivity detector
  • Adaptive AGC, DDE, 3D DNR
  • 720×540 resolution LCOS display
  • Built-in rechargeable Lithium battery
  • More than 7 hours continuous running (with Wi-Fi hotspot function off)
  • Wi-Fi hotspot
  • Type-C interface
  • Limited 3-year warranty

AGM Asp-Micro TM160 Thermal Monocular Data Sheet

Additional information

Weight 3 lbs
Dimensions 15 × 8 × 6 in
