InfiRay Outdoor MINI MH25 640X512 25mm Thermal Monocular


Out of stock

SKU: IRAY-MH25 Categories: ,


InfiRay Outdoor MINI MH25 640X512 25mm Thermal Monocular

(1-8x magnification and 1,400 yards of detection!)

Michigan residents please call and we will pay your sales tax! (No tax charged for other states if placing order on website.) (855) 766-4364

5-Year Full Manufacturers Warranty!

The InfiRay Outdoor MINI MH25 Thermal Monocular is the smallest fully multi-functional 12 micron thermal imaging monocular on the market. It can be used as a handheld monocular or helmet mounted monocular. The IRay Mini features bluetooth, picture-in-picture, and compatibility with rechargeable 16650 batteries as well as external power supply.

Flexible Mounting Options and Friendly Operation
For hands-free operation there are 2 mounting points designed to allow for a wide variety of dovetail helmet mounts. The Mini’s display icons flip automatically when orientation is flipped.

The InfiRay Outdoor MINI MH25 is operated by an intuitive clearly labeled menu and user friendly rotary button. This one button operation has positive clicks with each selection and allows for quick and easy operation without having to search for any buttons in the dark.

Power Supply Options
Using the included battery extender the Mini is compatible with CR123A, CR123, 16340, and 16650 batteries. Using 1 16650 the Mini will run for 3 hours, and using the included power cable with a 10,000 mah USB battery the Mini will run for 18 hours.

InfiRay Outdoor MINI MH25 Specifications:

Device Technology: Thermal Imaging
Sensor Resolution: 640×480
Optical Magnification: 1X
Digital Magnification: 8X
Sensor Pixel Size: 12 Micron
Sensor Frame Rate: 50hz
Objective Focal Length: 25mm
Objective Diameter: 25mm
Objective F#: 1
Detection Range: 1375
Onboard Recording: No

InfiRay Mini Thermal Monocular – Manual

Additional information

Weight 3 lbs
Dimensions 7 × 7 × 6 in
